SX5310ZLJMB246B
| Drive Form | 8X4 |
| Wheelbase | 1800+2375+1400mm |
| Engine | Weichai WP10.350E53 |
| Transmission | Fast 12JSD160T |
| Body Length | 8.36m |
| Body Width | 2.55m |
| Body Height | 3.45m |
| Front Track | 2070/2070mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 18°(°) |
| Departure Angle | 20°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard hydraulic mount, Skyhealth Smart Edition BD vehicle terminal, oil bath air filter, transmission with QH50 power take-off, 180Ah maintenance-free battery; transmission optional 12JSD160TA |
| Version | Urban Construction Standard Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP10.350E53 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 9.726L |
| Emission Standard | National Standard V |
| Max Horsepower | 350hp |
| Max Output Power | 257kW |
| Max Torque | 1600N·m |
| Max Torque Speed | 1200-1600rpm |
| Rated Speed | 1900rpm |
| Engine Type | Electronically controlled high pressure common rail +SCR |
| Transmission Model | Fast 12JSD160T |
| Transmission Brand | Fast |
| Shift Type | Manual |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 5.6m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.2m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | Standard Cab M |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 300L |
| Frame Size | 850×300(8+5)mm |
| Front Axle | MAN7.5T |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 16T MAN Double Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Leaf Springs | 10/10/12 |
| Clutch | Φ430 |
| Steering Gear | Domestic |
| Tire Spec | 12.00R20 |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Manual |
| Power Windows | ● |
| Electronic Central Lock | ○ |
| Aluminum Air Tank | ● |
SX3319HD346TL
| Drive Form | 8X4 |
| Wheelbase | 1800+3375+1400mm |
| Engine | Weichai WP10HNG350E60 |
| Transmission | Fast 10 |
| Rear Axle Ratio | 5.286 |
| Body Length | 9.7m |
| Body Width | 2.55m |
| Body Height | 3.6m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 16°(°) |
| Departure Angle | 25°(°) |
| Origin | Xi’an, Shaanxi |
| Energy Type | LNG |
| Engine Model | Weichai WP10HNG350E60 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | LNG |
| Displacement | 9.5L |
| Emission Standard | China VI |
| Max Horsepower | 350hp |
| Max Output Power | 257kW |
| Max Torque | 1600N·m |
| Max Torque Speed | 1100-1500rpm |
| Rated Speed | 1900rpm |
| Engine Type | SPI+ER+EGR+TWC |
| Transmission Model | Fast 10 |
| Transmission Brand | Fast |
| Forward Gears | 10-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6.5m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | backward dump |
| Unloading Type | backward dump |
| Frame Size | (970-850) ×300(single 10)mm |
| Front Axle | 5.5T Maintenance free |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 11.5T MAN Single Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.286 |
| Leaf Springs | 3/3/5,10/10/10,14/14/12,10/10/12 |
| Tire Spec | 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| Power Windows | ● |
SX3259MC384
| Drive Form | 6X4 |
| Wheelbase | 3775+1400mm |
| Engine | Weichai WP10H375E62 |
| Transmission | Fast 12 |
| Rear Axle Ratio | 5.92 |
| Body Length | 8.4m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2036mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 12.5t |
| Rated Payload | 12.37t |
| Gross Weight | 25t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 23°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Three-stage metal bumper, Skyhealth Smart Edition, oil bath air filter, reinforced transmission shaft, ABS, transmission flexible shaft with flexible shift, power take-off, engine under-vehicle start (WP model), water tank protective barrier |
| Version | Urban Construction Reinforced Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP10H375E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 9.5L |
| Emission Standard | China VI |
| Max Horsepower | 375hp |
| Max Output Power | 276kW |
| Max Torque | 1800N·m |
| Max Torque Speed | 1000-1400rpm |
| Rated Speed | 1900rpm |
| Engine Type | CR+DOC+DPF+Hi_SCR |
| Transmission Model | Fast 12 |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Cargo Box Length | 5.6m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | Extended flat cab |
| Cab Tilt | Electric |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 400L |
| Frame Size | 850×300(8+7)mm |
| Front Axle | MAN7.5T Front Axle |
| Front Axle Load Capacity | 7000kg |
| Rear Axle | 16T MAN Double Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.92 |
| Suspension Type (F/R) | Multi-leaf spring + four-horse riding |
| Leaf Springs | 10/12 |
| Tire Spec | 12.00R20 16PR |
| Tire Count | 10 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Electronic Central Lock | ● |
| Daytime Running Lights | ● |
SX3319HC346
| Drive Form | 8X4 |
| Wheelbase | 1800+3375+1400mm |
| Engine | Weichai WP10H375E62 |
| Transmission | Fast 12 |
| Rear Axle Ratio | 5.92 |
| Body Length | 9.6m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 28°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Three-stage metal bumper, Skyhealth Smart Edition, oil bath air filter, reinforced transmission shaft, ABS, transmission flexible shaft with flexible shift, power take-off, engine under-vehicle start (WP model), water tank protective barrier |
| Version | Urban Construction Standard Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP10H375E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 9.5L |
| Emission Standard | China VI |
| Max Horsepower | 375hp |
| Max Output Power | 276kW |
| Max Torque | 1800N·m |
| Max Torque Speed | 1000-1400rpm |
| Rated Speed | 1900rpm |
| Engine Type | CR+DOC+DPF+Hi_SCR |
| Transmission Model | Fast 12 |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6.5m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | Extended flat cab |
| Cab Tilt | Electric |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 300L |
| Frame Size | 850×300(8+5)mm |
| Front Axle | MAN7.5T Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 16T MAN Double Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.92 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 12.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Electronic Central Lock | ● |
| Daytime Running Lights | ● |
SX3319HD346
| Drive Form | 8X4 |
| Wheelbase | 1800+3375+1400mm |
| Engine | Weichai WP12.400E62 |
| Transmission | Fast 12 |
| Rear Axle Ratio | 5.92 |
| Body Length | 9.6m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 28°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Three-stage metal bumper, Skyhealth Smart Edition, oil bath air filter, reinforced transmission shaft, ABS, transmission flexible shaft with flexible shift, power take-off, engine under-vehicle start (WP model), water tank protective barrier |
| Version | Highway Standard Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP12.400E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 11.6L |
| Emission Standard | China VI |
| Max Horsepower | 400hp |
| Max Output Power | 294kW |
| Max Torque | 2000N·m |
| Max Torque Speed | 1000-1400rpm |
| Rated Speed | 1900rpm |
| Engine Type | CR+DOC+DPF+Hi_SCR |
| Transmission Model | Fast 12 |
| Transmission Brand | Fast |
| Shift Type | Manual |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6.5m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | Extended flat cab |
| Cab Width | 2550mm |
| Seating Capacity | 2 persons |
| Cab Tilt | Electric |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Capacity | 300L |
| Frame Size | 850×300(8+5)mm |
| Front Axle | MAN7.5T Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 16T MAN Double Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.92 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 12.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Electronic Central Lock | ● |
| Daytime Running Lights | ● |
SX3319HC426
| Drive Form | 8X4 |
| Wheelbase | 1800+4175+1400mm |
| Engine | Weichai WP10H375E62 |
| Transmission | Fast 12 |
| Rear Axle Ratio | 5.92 |
| Body Length | 10.7m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 17°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Three-stage metal bumper, Skyhealth Smart Edition, oil bath air filter, reinforced transmission shaft, ABS, transmission flexible shaft with flexible shift, power take-off, engine under-vehicle start (WP model), water tank protective barrier |
| Version | Highway Standard Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP10H375E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 9.5L |
| Emission Standard | China VI |
| Max Horsepower | 375hp |
| Max Output Power | 276kW |
| Max Torque | 1800N·m |
| Max Torque Speed | 1000-1400rpm |
| Rated Speed | 1900rpm |
| Engine Type | CR+DOC+DPF+Hi_SCR |
| Transmission Model | Fast 12 |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 7.6m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | Extended semi-high |
| Cab Tilt | Electric |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 300L |
| Frame Size | 850×300(8+5)mm |
| Front Axle | MAN7.5T Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 16T MAN Double Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.92 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 12.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Electronic Central Lock | ● |
| Daytime Running Lights | ● |
SX3319HD426
| Drive Form | 8X4 |
| Wheelbase | 1800+4175+1400mm |
| Engine | Xi'an Cummins X12NS6B400 |
| Transmission | Fast 12 |
| Rear Axle Ratio | 5.92 |
| Body Length | 10.7m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 17°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Three-stage metal bumper, Skyhealth Smart Edition, oil bath air filter, reinforced transmission shaft, ABS, transmission flexible shaft with flexible shift, power take-off, engine under-vehicle start (WP model), water tank protective barrier |
| Version | Highway Standard Edition |
| Energy Type | Diesel |
| Engine Model | Xi'an Cummins X12NS6B400 |
| Engine Brand | Xi'an Cummins |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 11.8L |
| Emission Standard | China VI |
| Max Horsepower | 400hp |
| Max Output Power | 301kW |
| Max Torque | 2100N·m |
| Max Torque Speed | 1000-1300rpm |
| Rated Speed | 1900rpm |
| Transmission Model | Fast 12 |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 7.6m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | Extended flat cab |
| Cab Tilt | Electric |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 400L |
| Frame Size | 850×300(8+5)mm |
| Front Axle | MAN7.5T Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 16T MAN Double Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.92 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 12.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Electronic Central Lock | ● |
| Daytime Running Lights | ● |
SX5319ZLJMD306TL
| Drive Form | 8X4 |
| Wheelbase | 1800+2975+1400mm |
| Engine | Weichai WP13NG430E61 |
| Transmission | Fast 12 |
| Rear Axle Ratio | 5.92 |
| Body Length | 9.35m |
| Body Width | 2.55m |
| Body Height | 3.6m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 16°(°) |
| Departure Angle | 25°(°) |
| Origin | Xi’an, Shaanxi |
| Version | Urban Construction Standard Edition |
| Energy Type | LNG |
| Engine Model | Weichai WP13NG430E61 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | LNG |
| Displacement | 12.54L |
| Emission Standard | China VI |
| Max Horsepower | 430hp |
| Max Output Power | 316kW |
| Max Torque | 2200N·m |
| Max Torque Speed | 1100-1300rpm |
| Rated Speed | 1900rpm |
| Engine Type | SPI+ER+EGR+TWC |
| Transmission Model | Fast 12 |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 5.6m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | backward dump |
| Unloading Type | backward dump |
| Cab Suspension | 4-point Air Suspension |
| Driver Seat Type | Air Suspension Seat |
| Frame Size | （970-850）×300(8+5)mm |
| Front Axle | 7.5T MAN |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 16T MAN Double Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.92 |
| Leaf Springs | 3/3/5,10/10/10,14/14/12,10/10/12 |
| Tire Spec | 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Electronic Central Lock | ● |
SX3319MD326TL
| Drive Form | 8X4 |
| Wheelbase | 1800+3175+1400mm |
| Engine | Weichai WP13NG430E61 |
| Transmission | Fast 12 |
| Rear Axle Ratio | 5.92 |
| Body Length | 9.75m |
| Body Width | 2.55m |
| Body Height | 3.6m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 16°(°) |
| Departure Angle | 25°(°) |
| Origin | Xi’an, Shaanxi |
| Version | Urban Construction Standard Edition |
| Energy Type | LNG |
| Engine Model | Weichai WP13NG430E61 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | LNG |
| Displacement | 12.54L |
| Emission Standard | China VI |
| Max Horsepower | 430hp |
| Max Output Power | 316kW |
| Max Torque | 2200N·m |
| Max Torque Speed | 1100-1300rpm |
| Rated Speed | 1900rpm |
| Engine Type | SPI+ER+EGR+TWC |
| Transmission Model | Fast 12 |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | backward dump |
| Unloading Type | backward dump |
| Cab Suspension | 4-point Air Suspension |
| Driver Seat Type | Air Suspension Seat |
| Frame Size | （970-850）×300(8+5)mm |
| Front Axle | 7.5T MAN |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 16T MAN Double Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.92 |
| Leaf Springs | 3/3/5,10/10/10,14/14/12,10/10/12 |
| Tire Spec | 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Electronic Central Lock | ● |
SX3319HD346TL
| Drive Form | 8X4 |
| Wheelbase | 1800+3375+1400mm |
| Engine | Weichai WP13NG430E61 |
| Transmission | Fast 12 |
| Rear Axle Ratio | 5.92 |
| Body Length | 9.7m |
| Body Width | 2.55m |
| Body Height | 3.6m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 16°(°) |
| Departure Angle | 25°(°) |
| Origin | Xi’an, Shaanxi |
| Version | Highway Standard Edition |
| Energy Type | LNG |
| Engine Model | Weichai WP13NG430E61 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | LNG |
| Displacement | 12.54L |
| Emission Standard | China VI |
| Max Horsepower | 430hp |
| Max Output Power | 316kW |
| Max Torque | 2200N·m |
| Max Torque Speed | 1100-1300rpm |
| Rated Speed | 1900rpm |
| Engine Type | SPI+ER+EGR+TWC |
| Transmission Model | Fast 12 |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6.5m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | backward dump |
| Unloading Type | backward dump |
| Cab Suspension | 4-point Air Suspension |
| Driver Seat Type | Air Suspension Seat |
| Frame Size | （970-850）×300(8+5)mm |
| Front Axle | 7.5T MAN |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 16T MAN Double Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.92 |
| Leaf Springs | 3/3/5,10/10/10,14/14/12,10/10/12 |
| Tire Spec | 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Electronic Central Lock | ● |
SX3319HD406TL
| Drive Form | 8X4 |
| Wheelbase | 1800+3975+1400mm |
| Engine | Weichai WP13NG430E61 |
| Transmission | Fast 12 |
| Rear Axle Ratio | 5.92 |
| Body Length | 10.8m |
| Body Width | 2.55m |
| Body Height | 3.6m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 16°(°) |
| Departure Angle | 25°(°) |
| Origin | Xi’an, Shaanxi |
| Version | Highway Standard Edition |
| Energy Type | LNG |
| Engine Model | Weichai WP13NG430E61 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | LNG |
| Displacement | 12.54L |
| Emission Standard | China VI |
| Max Horsepower | 430hp |
| Max Output Power | 316kW |
| Max Torque | 2200N·m |
| Max Torque Speed | 1100-1300rpm |
| Rated Speed | 1900rpm |
| Engine Type | SPI+ER+EGR+TWC |
| Transmission Model | Fast 12 |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 7.6m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | backward dump |
| Unloading Type | backward dump |
| Cab Suspension | 4-point Air Suspension |
| Driver Seat Type | Air Suspension Seat |
| Frame Size | （970-850）×300(8+5)mm |
| Front Axle | 7.5T MAN |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 16T MAN Double Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.92 |
| Leaf Springs | 3/3/5,10/10/10,14/14/12,10/10/12 |
| Tire Spec | 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Electronic Central Lock | ● |
SX3319HC346
| Drive Form | 8X4 |
| Wheelbase | 1950+3225+1400mm |
| Engine | Weichai WP9H350E62 |
| Transmission | Fast 12 |
| Rear Axle Ratio | 5.286 |
| Body Length | 9.6m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 28°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard configuration: three-stage non-metallic bumper air main seat, hydraulic suspension, Tianxing Jianzhiya version, desert air filter, transmission flexible shaft with flexible shift, power take-off, two-stage boarding pedal, engine under-vehicle start (WP model), water tank protective fence, manual turnover; Optional: standard cab (M), electric turnover, oil bath air filter, 12R22.5 vacuum tire, reserved water tank position, three-stage boarding step |
| Energy Type | Diesel |
| Engine Model | Weichai WP9H350E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 8.8L |
| Emission Standard | China VI |
| Max Horsepower | 350hp |
| Max Output Power | 257kW |
| Max Torque | 1700N·m |
| Max Torque Speed | 1100-1400rpm |
| Rated Speed | 1900rpm |
| Engine Type | CR+DOC+DPF+Hi_SCR |
| Transmission Model | Fast 12 |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6.5m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | Extended semi-high |
| Cab Width | 2550mm |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 400L |
| Frame Size | 850×270(8+5)mm |
| Front Axle | MAN5.5T Lightweight |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | 13T MAN Single Stage |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.286 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 12.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Power Mirrors | ○ |
| Heated Mirrors | ○ |
| Electronic Central Lock | ● |
| Daytime Running Lights | ● |
SX3319MB256
| Drive Form | 8X4 |
| Wheelbase | 1950+2325+1400mm |
| Engine | Weichai WP8.350E62 |
| Transmission | Fast S12MOQ |
| Rear Axle Ratio | 5.92 |
| Body Length | 8.7m |
| Body Width | 2.55m |
| Body Height | 3.25m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 13t |
| Rated Payload | 17.87t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 24°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard: Bumper for engineering vehicles, engineering appearance, oil bath air filter, flexible shift, hydraulic suspension, power take-off, two-stage boarding step, maintenance-free battery, water tank protection fence, speed limit 89km/h; Optional: Special configuration package for muck truck, Tianxing Jianzhiya version, electric turnover, three-stage boarding step, wiper + forward extension rearview mirror, LED headlight, off-road pattern tire, mining pattern tire, 180Ah maintenance-free battery, 12R22.5 vacuum tire, expansion configuration package (co-driver ashtray, transmission auxiliary support, jack, crowbar, vehicle kit) |
| Version | Urban Construction Standard Load Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP8.350E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 7.8L |
| Emission Standard | China VI |
| Max Horsepower | 350hp |
| Max Output Power | 257kW |
| Max Torque | 1400N·m |
| Max Torque Speed | 1200-1600rpm |
| Rated Speed | 2100rpm |
| Transmission Model | Fast S12MOQ |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 5.6m |
| Cargo Box Width | 2.3m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | standard cab |
| Cab Width | 2550mm |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 300L |
| Frame Size | 850×300(8+5)mm |
| Front Axle | Drum Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | Drum Drive Axle |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.92 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 11.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Power Mirrors | ○ |
| Heated Mirrors | ○ |
| Reversing Camera | ○ |
| Aluminum Air Tank | ● |
| Daytime Running Lights | ● |
| Front Brake | Drum |
| Rear Brake | Drum |
SX3319HC276
| Drive Form | 8X4 |
| Wheelbase | 1950+2525+1400mm |
| Engine | Weichai WP9H390E62 |
| Transmission | Fast S12MOQ |
| Rear Axle Ratio | 5.262 |
| Body Length | 8.7m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 23°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard: Bumper for engineering vehicles, engineering appearance, oil bath air filter, flexible shift, hydraulic suspension, power take-off, two-stage boarding step, maintenance-free battery, water tank protection fence, speed limit 89km/h; Optional: Special configuration package for muck truck, Tianxing Jianzhiya version, electric turnover, three-stage boarding step, wiper + forward extension rearview mirror, LED headlight, off-road pattern tire, mining pattern tire, 180Ah maintenance-free battery, 12R22.5 vacuum tire, expansion configuration package (co-driver ashtray, transmission auxiliary support, jack, crowbar, vehicle kit) |
| Version | Urban Construction Standard Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP9H390E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 8.8L |
| Emission Standard | China VI |
| Max Horsepower | 390hp |
| Max Output Power | 287kW |
| Max Torque | 1700N·m |
| Max Torque Speed | 1100-1400rpm |
| Rated Speed | 2100rpm |
| Engine Type | Electronically controlled high pressure common rail +DOC+DPF+Hi_SCR |
| Transmission Model | Fast S12MOQ |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Cargo Box Length | 5.6m |
| Cargo Box Width | 2.3m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | standard cab |
| Cab Width | 2550mm |
| Driver Seat Type | Air Suspension Seat |
| Frame Size | 850×300(8+5)mm |
| Front Axle | Drum Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | Drum Drive Axle |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.262 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 12.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Power Mirrors | ○ |
| Heated Mirrors | ○ |
| Reversing Camera | ○ |
| Aluminum Air Tank | ● |
| Daytime Running Lights | ● |
| Front Brake | Drum |
| Rear Brake | Drum |
SX3319HC276
| Drive Form | 8X4 |
| Wheelbase | 1950+2525+1400mm |
| Engine | Weichai WP9H390E62 |
| Transmission | Fast S12MOQ |
| Rear Axle Ratio | 5.262 |
| Body Length | 8.9m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2070/2070mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 23°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard: Bumper for engineering vehicles, engineering appearance, oil bath air filter, flexible shift, hydraulic suspension, power take-off, two-stage boarding step, maintenance-free battery, water tank protection fence, speed limit 89km/h; Optional: Special configuration package for muck truck, Tianxing Jianzhiya version, electric turnover, three-stage boarding step, wiper + forward extension rearview mirror, LED headlight, off-road pattern tire, mining pattern tire, 180Ah maintenance-free battery, 12R22.5 vacuum tire, expansion configuration package (co-driver ashtray, transmission auxiliary support, jack, crowbar, vehicle kit) |
| Version | Urban Construction Standard Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP9H390E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 8.8L |
| Emission Standard | China VI |
| Max Horsepower | 390hp |
| Max Output Power | 287kW |
| Max Torque | 1700N·m |
| Max Torque Speed | 1100-1400rpm |
| Rated Speed | 2100rpm |
| Engine Type | Electronically controlled high pressure common rail +DOC+DPF+Hi_SCR |
| Transmission Model | Fast S12MOQ |
| Transmission Brand | Fast |
| Shift Type | Manual |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Cargo Box Length | 5.8m |
| Cargo Box Width | 2.3m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | standard cab |
| Cab Width | 2550mm |
| Seating Capacity | 2 persons |
| Driver Seat Type | Air Suspension Seat |
| Frame Size | 850×300(8+5)mm |
| Front Axle | Drum Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | Drum Drive Axle |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.262 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 12.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Power Mirrors | ○ |
| Heated Mirrors | ○ |
| Reversing Camera | ○ |
| Aluminum Air Tank | ● |
| Daytime Running Lights | ● |
| Front Brake | Drum |
| Rear Brake | Drum |
SX3319HB346Q1
| Drive Form | 8X4 |
| Wheelbase | 1950+3225+1400mm |
| Engine | Weichai WP8.350E62 |
| Transmission | Fast S10MDQ |
| Rear Axle Ratio | 5.286 |
| Body Length | 9.6m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 13t |
| Rated Payload | 17.87t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 28°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard configuration: bumper for engineering vehicle, desert air filter, flexible shift, hydraulic suspension, power take-off, two-stage boarding step, maintenance-free battery, water tank protection fence, speed limit 89km/h; optional: Tianxing Jianzhiya version, electric turnover, 12R22.5 vacuum tire, expansion configuration package (co-driver ashtray, transmission auxiliary support, jack, crowbar, vehicle kit) |
| Version | Lightweight Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP8.350E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 7.8L |
| Emission Standard | China VI |
| Max Horsepower | 350hp |
| Max Output Power | 257kW |
| Max Torque | 1400N·m |
| Max Torque Speed | 1200-1600rpm |
| Rated Speed | 2100rpm |
| Transmission Model | Fast S10MDQ |
| Transmission Brand | Fast |
| Forward Gears | 10-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6.5m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | standard cab |
| Cab Width | 2550mm |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 400L |
| Frame Size | 850×270(8+4)mm |
| Front Axle | Drum Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | Drum Drive Axle |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.286 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 11.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Power Mirrors | ○ |
| Heated Mirrors | ○ |
| Reversing Camera | ○ |
| Aluminum Air Tank | ● |
| Daytime Running Lights | ● |
| Front Brake | Drum |
| Rear Brake | Drum |
SX3319HB366Q1
| Drive Form | 8X4 |
| Wheelbase | 1950+3425+1400mm |
| Engine | Weichai WP8.350E62 |
| Transmission | Fast S10MDQ |
| Rear Axle Ratio | 5.286 |
| Body Length | 9.9m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 13t |
| Rated Payload | 17.87t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 20°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard configuration: bumper for engineering vehicle, desert air filter, flexible shift, hydraulic suspension, power take-off, two-stage boarding step, maintenance-free battery, water tank protection fence, speed limit 89km/h; optional: Tianxing Jianzhiya version, electric turnover, 12R22.5 vacuum tire, expansion configuration package (co-driver ashtray, transmission auxiliary support, jack, crowbar, vehicle kit) |
| Version | Lightweight Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP8.350E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 7.8L |
| Emission Standard | China VI |
| Max Horsepower | 350hp |
| Max Output Power | 257kW |
| Max Torque | 1400N·m |
| Max Torque Speed | 1200-1600rpm |
| Rated Speed | 2100rpm |
| Transmission Model | Fast S10MDQ |
| Transmission Brand | Fast |
| Forward Gears | 10-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6.8m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | standard cab |
| Cab Width | 2550mm |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 400L |
| Frame Size | 850×270(8+4)mm |
| Front Axle | Drum Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | Drum Drive Axle |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.286 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 11.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Power Mirrors | ○ |
| Heated Mirrors | ○ |
| Reversing Camera | ○ |
| Aluminum Air Tank | ● |
| Daytime Running Lights | ● |
| Front Brake | Drum |
| Rear Brake | Drum |
SX3319HB346Q1
| Drive Form | 8X4 |
| Wheelbase | 1950+3225+1400mm |
| Engine | Weichai WP9H390E62 |
| Transmission | Fast S10MDQ |
| Rear Axle Ratio | 5.286 |
| Body Length | 9.6m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 13t |
| Rated Payload | 17.87t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 28°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard configuration: bumper for engineering vehicle, desert air filter, flexible shift, hydraulic suspension, power take-off, two-stage boarding step, maintenance-free battery, water tank protection fence, speed limit 89km/h; optional: Tianxing Jianzhiya version, electric turnover, 12R22.5 vacuum tire, expansion configuration package (co-driver ashtray, transmission auxiliary support, jack, crowbar, vehicle kit) |
| Version | Lightweight Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP9H390E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 8.8L |
| Emission Standard | China VI |
| Max Horsepower | 390hp |
| Max Output Power | 287kW |
| Max Torque | 1700N·m |
| Max Torque Speed | 1100-1400rpm |
| Rated Speed | 2100rpm |
| Engine Type | Electronically controlled high pressure common rail +DOC+DPF+Hi_SCR |
| Transmission Model | Fast S10MDQ |
| Transmission Brand | Fast |
| Forward Gears | 10-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6.5m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | standard cab |
| Cab Width | 2550mm |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 400L |
| Frame Size | 850×270(8+5)mm |
| Front Axle | Drum Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | Drum Drive Axle |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.286 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 11.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Power Mirrors | ○ |
| Heated Mirrors | ○ |
| Reversing Camera | ○ |
| Aluminum Air Tank | ● |
| Daytime Running Lights | ● |
| Front Brake | Drum |
| Rear Brake | Drum |
SX3319HB366Q1
| Drive Form | 8X4 |
| Wheelbase | 1950+3425+1400mm |
| Engine | Weichai WP9H390E62 |
| Transmission | Fast S10MDQ |
| Rear Axle Ratio | 5.286 |
| Body Length | 9.9m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 13t |
| Rated Payload | 17.87t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 20°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard configuration: bumper for engineering vehicle, desert air filter, flexible shift, hydraulic suspension, power take-off, two-stage boarding step, maintenance-free battery, water tank protection fence, speed limit 89km/h; optional: Tianxing Jianzhiya version, electric turnover, 12R22.5 vacuum tire, expansion configuration package (co-driver ashtray, transmission auxiliary support, jack, crowbar, vehicle kit) |
| Version | Lightweight Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP9H390E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 8.8L |
| Emission Standard | China VI |
| Max Horsepower | 390hp |
| Max Output Power | 287kW |
| Max Torque | 1700N·m |
| Max Torque Speed | 1100-1400rpm |
| Rated Speed | 2100rpm |
| Engine Type | Electronically controlled high pressure common rail +DOC+DPF+Hi_SCR |
| Transmission Model | Fast S10MDQ |
| Transmission Brand | Fast |
| Forward Gears | 10-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6.8m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | standard cab |
| Cab Width | 2550mm |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 400L |
| Frame Size | 850×270(8+4)mm |
| Front Axle | Drum Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | Drum Drive Axle |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.286 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 11.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Power Mirrors | ○ |
| Heated Mirrors | ○ |
| Reversing Camera | ○ |
| Aluminum Air Tank | ● |
| Daytime Running Lights | ● |
| Front Brake | Drum |
| Rear Brake | Drum |
SX3319HC366
| Drive Form | 8X4 |
| Wheelbase | 1950+3425+1400mm |
| Engine | Weichai WP9H390E62 |
| Transmission | Fast S12MDQ |
| Rear Axle Ratio | 5.262 |
| Body Length | 9.9m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2011/2011mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5t |
| Rated Payload | 15.37t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 20°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard: Engineering vehicle bumper, flexible gear shift, desert air filter, hydraulic mount, power take-off, two-stage boarding step, maintenance-free battery, water tank protective fence, speed limit 89km/h; Optional: M3000L standard cab without air deflector, oil bath air filter, Skywalker Smart Edition, electric flip, 12R22.5 vacuum tire, 180Ah maintenance-free battery, expansion configuration package (co-driver ashtray, transmission auxiliary support, jack, crowbar, onboard tool kit) |
| Version | Composite Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP9H390E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 8.8L |
| Emission Standard | China VI |
| Max Horsepower | 390hp |
| Max Output Power | 287kW |
| Max Torque | 1700N·m |
| Max Torque Speed | 1100-1400rpm |
| Rated Speed | 2100rpm |
| Engine Type | Electronically controlled high pressure common rail +DOC+DPF+Hi_SCR |
| Transmission Model | Fast S12MDQ |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 6.8m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | Extended semi-high |
| Cab Width | 2550mm |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 400L |
| Frame Size | 850×300(8+5)mm |
| Front Axle | Drum Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | Drum Drive Axle |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.262 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 11.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Power Mirrors | ○ |
| Heated Mirrors | ○ |
| Reversing Camera | ○ |
| Aluminum Air Tank | ● |
| Daytime Running Lights | ● |
| Front Brake | Drum |
| Rear Brake | Drum |
SX3319HC386
| Drive Form | 8X4 |
| Wheelbase | 1950+3625+1400mm |
| Engine | Weichai WP9H390E62 |
| Transmission | Fast S12MDQ |
| Rear Axle Ratio | 5.262 |
| Body Length | 10.3m |
| Body Width | 2.55m |
| Body Height | 3.5m |
| Front Track | 2070/2070mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 14.7t |
| Rated Payload | 16.17t |
| Gross Weight | 31t |
| Weight Class | Heavy-duty Truck |
| Approach Angle | 17°(°) |
| Departure Angle | 23°(°) |
| Origin | Xi’an, Shaanxi |
| Remarks | Standard: Engineering vehicle bumper, flexible gear shift, desert air filter, hydraulic mount, power take-off, two-stage boarding step, maintenance-free battery, water tank protective fence, speed limit 89km/h; Optional: M3000L standard cab without air deflector, oil bath air filter, Skywalker Smart Edition, electric flip, 12R22.5 vacuum tire, 180Ah maintenance-free battery, expansion configuration package (co-driver ashtray, transmission auxiliary support, jack, crowbar, onboard tool kit) |
| Version | Composite Edition |
| Energy Type | Diesel |
| Engine Model | Weichai WP9H390E62 |
| Engine Brand | Weichai |
| Cylinders | 6 cyl |
| Fuel Type | Diesel |
| Displacement | 8.8L |
| Emission Standard | China VI |
| Max Horsepower | 390hp |
| Max Output Power | 287kW |
| Max Torque | 1700N·m |
| Max Torque Speed | 1100-1400rpm |
| Rated Speed | 2100rpm |
| Engine Type | Electronically controlled high pressure common rail +DOC+DPF+Hi_SCR |
| Transmission Model | Fast S12MDQ |
| Transmission Brand | Fast |
| Forward Gears | 12-speed |
| Reverse Gears | 2 pcs |
| Housing Material | Aluminum Housing |
| Cargo Box Length | 7.2m |
| Cargo Box Width | 2.35m |
| Cargo Box Height | 1.5m |
| Cargo Box Type | Dump Type |
| Unloading Type | Dump Type |
| Cabin | Extended semi-high |
| Cab Width | 2550mm |
| Driver Seat Type | Air Suspension Seat |
| Fuel Tank Material | Aluminum Alloy |
| Fuel Tank Capacity | 400L |
| Frame Size | 850×300(8+5)mm |
| Front Axle | Drum Front Axle |
| Front Axle Load Capacity | 6500/6500kg |
| Rear Axle | Drum Drive Axle |
| Rear Axle Load Capacity | 18000(two-axis group)kg |
| Axle Ratio | 5.262 |
| Suspension Type (F/R) | Multi-leaf Springs + 4 U-bolts |
| Leaf Springs | 14/14/12 |
| Tire Spec | 11.00R20 18PR |
| Tire Count | 12 pcs |
| ABS | ● |
| A/C Type | Automatic |
| Power Windows | ● |
| Power Mirrors | ○ |
| Heated Mirrors | ○ |
| Reversing Camera | ○ |
| Aluminum Air Tank | ● |
| Daytime Running Lights | ● |
| Front Brake | Drum |
| Rear Brake | Drum |
Delivery & Logistics
Production Lead Time25–50 days from PO + deposit
Sea Freight14–21 days to major SEA ports
Destination PortsTanjung Priok, Surabaya, Belawan, Cat Lai, Hai Phong, Cai Mep, Laem Chabang, Map Ta Phut
DocumentationCOO, Form E (ATIGA), Bilingual invoice, SNI test reports
FAQ
Q1: How do I know this used machine is in good condition?
A:
Every machine is carefully selected, inspected, and tested before sale. We only export equipment that passes our internal quality check on engine performance, hydraulic system, and structural condition. All photos and videos of used machines displayed on our website are real. So you can see the exact condition before making a decision.
Q2: Do you help with shipping and customs clearance?
A:
Yes. We provide full export support from start to finish. Our team helps you reduce risk and simplify the entire buying process.
Q3: Why should I buy used construction machinery from you?
A:
We are a subsidiary of XCMG (Xuzhou Construction Machinery Group), not a trading company or middleman. All Used Equipment is handled through a factory-direct process, including inspection, refurbishment, testing, and export procedures carried out under strict quality control standards.
This means you get:
1.Direct factory supply (no middlemen markup)
2.Authentic XCMG Equipment with traceable origin
3.Standardized inspection and testing process
4.Fully compliant export documentation
5.More stable quality and after-sales support system
We focus on providing reliable, transparent, and factory-supported used machinery solutions to global customers.
Q4: Can I inspect or verify the machine before buying?
A:
Yes. We fully support machine verification before purchase. If you cannot visit in person, we can provide live video inspection or third-party inspection services to ensure transparency.
Q5: How do I place an order?
A:
1.Send inquiry with model you want
2. We confirm availability and send details
3. You review videos and photos
4. Confirm order and pay deposit
5. We arrange shipment
Fast response via WhatsApp is available for quicker communication.
Our Services
✅ Pre-shipment Inspection: We provide a full inspection process before shipment, including machine testing, condition verification, and detailed reporting. Real working videos and photos are available so you can confirm the exact machine condition before delivery.
✅ Spare Parts Supply: We supply original XCMG Spare Parts at factory-direct pricing. Fast global shipping ensures your machine stays in operation with minimal downtime.
✅ After-sales Support: We provide 24/7 online technical support to assist with installation, operation, and maintenance issues.
Our Team
Reconditioning and Repairing Team
Refurbish core parts to restore capacity. Replace all worn parts with genuine XCMG new ones.
Issuing Report Team
Certified examiner inspects, tests and certifies the reconditioned machine. SGS provides the third-party inspection certificate.
Our Factory
